| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Portable Hydraulic Auger Drill Machine,Hydraulic Auger |
| Driven Type | Hydraulic |
| Color | Light Grey,Blue/red/yellow/grey |
| Click to view more | |
Product Details
Technical Specification-Portable Hydraulic Auger Drill Machine (Water Well)
Parameter---------------------------------------Specifications
Drilling Depth-----------------------------------30-50 meters(depends on soil type and auger length)
Drilling Diameter-------------------------------100 MM to 300 MM
Power Source-----------------------------------Diesel Engine (10-20 HP)
Hydraulic pump flow---------------------------20-30 LPM @ 200 bar
Auger Rotation Speed--------------------------100-250 RPM (Adjustable)
Hydraulic oil tank-------------------------------35-50 litter
pull up force------------------------------------1-2 ton ( via Hydraulic cylinder)
Machine Weight---------------------------------400-600 Kgs
Chassis Type------------------------------------ Two wheel trailor-mouted,towable
Control-------------------------------------------Manually hydraulic lever controls
Mobility------------------------------------------Jeep towable/Hand Move/tractor Move etc..
optional Features------------------------------- Centrifugal pump,water injection,core barrel,rock auger bits.
